Peterbilt 348 2017 - Description of Warning Symbols

WARNINGSYMBOLS
DescriptionofWarning
Symbols
1.ActiveWarnings,Exclamation
Point
Illuminateswhenaredwarningis
active.UsetheMCSknobtoviewthe
warningsthatareactive.
2.ActiveWarnings,Number
Illuminatesthetotalnumberofred
andyellowactivewarnings.Usethe
MCStoviewtheactivewarningsifthe
displayshowsa>symbol.
3.ActiveWarnings,Triangle
Illuminateswhenayellowwarningis
active.UsetheMCSknobtoviewthe
warningsthatareactive.
4.Alternator
Illuminatesifthealternatorisnot
charging.(Foralternatorswithwarning
lampoutputsignal.)
5.Anti-LockBrakeSystem
(ABS)
IlluminatesduringtheInstrumentation
SystemSelfT est.HavetheABS
systemcheckedbyaPeterbiltdealer
iftheABSWarningLampstaysonfor
morethan3seconds.
Illuminatesduringnormaloperating
conditionstoindicateaproblemwith
theABSSystem.
Illuminateswhenaproblemexists
withtheoptionalWheelSpinControl
feature.
6.Anti-LockBrakeSystem
(ABS),Trailer
IlluminatesduringtheInstrumentation
SystemSelfTestandthetractor/truck
isconnectedwithaABSequipped
trailer.
Illuminatesduringnormaloperating
conditionstoindicateaproblemwith
theTrailerABSSystem.Thisshould
becheckedbyaPeterbiltdealeras
soonaspossible.
