15-07-2002
PEUGEOT SERVICING
25
All driving conditions o Arduous conditions * According to destination
A AND C SERVICE LEVELS AND THE INTERMEDIATE VISIT
Level
Operations Description of operations
1st service
AC
Intermediate visit
DRAIN AND REFILL
- Engine oil.
- Bleed fuel filter (diesel only).
- Oil filter.
- Fuel filter* (petrol).
REPLACE
- Fuel filter (diesel).
- Air filter element.
- Spark plugs (petrol).
- Engine oil (check + top up).
- Manual gearbox oil (check + top up).
- Battery (check + top up) if cap is removable.
LEVELS
- Screen wash (check + top-up)
- Coolant (check + top up).
- Brake fluid (check + top up).
- Power steering fluid (check + top up, according to specification).
- Operation of lights and indicators.
- Condition of glass, headlamp and light lenses and mirrors.
- Horn.
- Windscreen washer jets.
- Condition of wiper blades.
- Condition and tension of the ancillary drive belts.
- Handbrake.
- Condition of hydraulic circuits (hoses and covers) and check for leaks.
CHECK
- Condition of rubber boots and gaiters.
- Brake pad wear.
- Play in hubs, link rods, ball joints, flexible mountings.
- Shock absorbers for leaks.
- Rear drum brake lining wear.
- Condition and pressure of tyres (including spare wheel).
- Emission control check according to current legislation (petrol).
- Smoke opacity (diesel).
- Pollen filter (according to specification).
- Visual check of the whole vehicle by a Peugeot technician.
SERVICE
- Courtesy vehicle
ROAD TEST
