Pfaff 3371-10 series Adjustment Manual

Adjustment
12
Fig. 15 - 08
2
1
2
1
A
B
15.13 Aligning the hook race cover
Requirement
The needle should be centred to cutout B and the rear side of the needle flush to the
imaginary line A.
● Move the hook race cover 1 (screws 2) in accordance with the requirement.
