Adjustment
32
15
.33 List of parameters
Group Parameter Description Setting Set value
range
000 001 Maximum speed 500 – 2500 2500
This parameter is used to fix the max.
sewing speed (upper limit).
002 Sewing speed for start stitches
With this parameter the speeds for
the 5 start stitches are fixed.
Speed (spm) for start stitch no. 1 500 – 2500 500
Speed (spm) for start stitch no. 2 500 – 2500 900
Speed (spm) for start stitch no. 3 500 – 2500 2500
Speed (spm) for start stitch no. 4 500 – 2500 2500
Speed (spm) for start stitch no. 5 500 – 2500 2500
003 Locking/releasing seam patterns ON – OFF ON
This parameter is used to release (ON)
or lock (OFF) the individual seam
patterns (0 to 99) to be carried out in
the sewing mode.
004 Switch bobbin thread counter on/off ON – OFF OFF
Standard value (pieces per bobbin) 1 - 9999
In the sewing mode, the bobbin thread
counter counts the pieces sewn
backwards from the standard value.
If the bobbin thread counter is
switched on, in the sewing mode a
signal is given when the value 0 is
reached.
005 Sequence combination
This parameter is used to combine 0 - 4 0
several sequences with each other.
0 = no combination
1 = C1 with C2
2 = C2 with C3
3 = C1 with C3
4 = C1 with C2 and C3
006 Reversing after thread trimming ON – OFF OFF
Reverse position [°] 0 – 14 11
With this parameter it is possible to
switch the automatic reversing function
after thread trimming on or off. If the
reversing function is switched on, the
reverse position can be set by turning
the balance wheel. The access code is
necessary for this adjustment.
