Pfaff 3371-10 series Adjustment Manual

Adjustment
20
15
.21 Adjusting the trimmer solenoid
Requirement
When the thread trimmer is in its neutral position, solenoid 1 should be at a distance
of 5 mm from the case.
● Turn nut 1 (nut 2) in accordance with the requirement.
Fig. 15 - 16
5 mm
2
1
