Adjustment
29
15
.30 Changing the feeder and the jaws of the button clamp
● Measure the cutout of the new feeder in X- and Y-direction and adjust the sewing area
size, see Chapter 9.07 Button clamp and sewing area size of the instruction manual.
● Fit and align the new button clamp jaws, see Chapter 15.08 Aligning the button clamp.
● Select the seam program to match the button clamp, see Chapter 9.06 Selecting a
seam program of the instruction manual.
● Check the seam program by tacting through it, see Chapter 7.05.03 Function keys of
the instruction manual.
If the actual size of the sewing area differs from the size entered, serious
damage can be caused to the machine!
Fig. 15 - 26
X
Y
1
