Input
42
11.04 Free input of the seam pattern (Teach in))
In addition to the selection of firmly stored seam patterns (see Chapter 11.06 Summary of
the seam patterns), there is also a possibility of setting seam patterns (button type) as desi-
red using the corresponding parameter input.
The program numbers
P50 to P99 are reserved for the free input of seam pat-
terns.
Call up the Input mode by pressing the TE key
(LED is illuminated).●
No VAL
001 2500
With the corresponding +/- keys, select the parameter 201 to enter the program number.●
No VAL
201 50
With the corresponding +/- keys, select the desired program number.
With the corresponding +/- keys
, select the parameter 202 to enter the button type.
With the corresponding +/- keys, select the desired button type.
(2 = two-hole button, 3 = three-hole button, 4 = four-hole button)
With the corresponding +/- keys
, select the parameters 203 - 208 in turn to enter the co-
ordinates of the buttonholes 1 - 6, and enter the relevant values for the X- and Y-direction.
If necessary, with the corresponding +/- keys
, select the parameter 209 to enter the
number of stitch positions and enter the desired value.
If necessary, with the corresponding +/- keys
, select the parameter 210 to choose the
stitch formation.
The stitch formation can only be chosen for three- and four-hole buttons and depends on
the previously selected button type.
●
●
●
●
●
●
