Setting up
34
9.10 Shifting the seam pattern
To adapt the seam patterns to formed workpiece holders, selected seam patterns can be
shifted.
From the basic position of the machine select the desired program station, e.g. P1.
Tact through the seam pattern, e.g. forwards.
The actual coordinates are shown together with the shift values for each stitch.
●
●
X: Y:
169+0 -99+10
With the corresponding +/- keys it is possible to enter a shift value for the entire seam
pattern in X- or Y-direction at each seam pattern coordinate.
The seam pattern shift is allocated to the respective actual program station and
is deleted when the program number is changed.
●
