Control elements
16
Fig. 7 - 03
1
7.04 Lever for adjusting the button clamp size
Adjust lever 1 to set the size of the but-
ton clamp. To do so, loosen screw 2.
After screw 2 has been loose-
ned, the clamp jaws close auto-
matically! Danger of crushing in
the button clamp zone!
●
1
2
Fig. 7 - 04
7.03 Balance wheel
By pressing and holding down balance
wheel 1, it is possible to adjust the need-
le bar manually.
●
