Input
62
Group
Gruppe
Parameter
Parameter
Description
Bedeutung
Setting
range
Set value
600
601
Display inputs
With this function the digital inputs
can be checked. "IN" shows the input
numbers (1 - 16). Under "VAL" the re-
spective switch status is displayed.
IN VAL
1 IN1, programmable input 1
2 IN2, programmable input 2
3 E3, button clamp raised
4
5
6
7
8
9
10
11
12
13
14
15
16
602 Display special inputs
With this function it is possible to
check the special inputs pedal,
reference X (SM1) and reference Y
(SM2). "IN" shows the inputs (PED,
REFX, REFY). Under "VAL" the
respective switch status is displayed.
IN VAL
PED Pedal (speed control unit
-1; 0; +1; 2)
REFX Reference input X
REFY Reference input Y
