7:2
C
B
A
B
F
D
C
E
When removing the embroidery unit
IURPWKHER[IRUWKHÀUVWWLPHEHVXUH
the shipping brace on the underside of
the embroidery unit has been removed.
Embroidery mode - preparations
(PEURLGHU\XQLWoverview
(type BE20)
A Embroidery unit release button
B Level adjusting feet
C Embroidery unit accessory tray (only on the large
embroidery unit, part number 850 135-096)
D Embroidery unit socket
E Embroidery hoop connection assembly
F Embroidery arm
(PEURLGHU\XQLWDFFHVVRU\WUD\
Use the tray in the embroidery unit to store
accessories used for embroidering.
(PEURLGHU\PRGHSUHSDUDWLRQV
The PFAFF
®
creative™ 4.5 sewing machine has all of the top features for every sewing need. For those who
want more, it also has embroidery capabilities. There are two optional embroidery units that can be used:
one large (part number 850135-096, type BE20) and one small unit (part number 850151-096, type BE16).
The embroidery units are available at your local authorized PFAFF
®
dealer.
The selection of hoops differs depending on which embroidery unit you choose for your PFAFF
®
creative
™
4.5
sewing and embroidery machine.
The following hoops are standard accessories for the large embroidery unit:
• creative™ 120 Square Hoop (120x120 mm)
• creative™ Master Hoop (240x150 mm)
• creative™ Deluxe Hoop (360x200 mm)
The following hoops are standard accessories for the small embroidery unit:
• creative™ 120 Square Hoop (120x120 mm)
• creative™ Elite Hoop (260x200 mm)
Several optional hoops are avialable at your authorized PFAFF
®
dealer.

Pfaff creative 4.5 Specifications

General

Display	Color touch screen
Automatic Thread Cutter	Yes
USB Connectivity	Yes
Stitch Width	9mm
Stitch Length	6mm
Type	Computerized Sewing and Embroidery Machine
