8.4.8 Entering thread trimming in program 3, at the end of seam section 3:
In order for thread trimming to be carried out at the end of "Program 3" and "Seam section 3"
proceed as follows:
8.1 Press the PM key, (LED on) and press the TE key, (LED on)
8.2 Press the paging key until the display Fig. 8.12 appears
8.3 Set program number "3" with the A+ / A- keys,
8.4 Set seam section "3" with the B+ / B- keys,
8.5 Press the TE key, (LED off), values are accepted!
8.6 Switch on using the "Thread trimming at seam end" key, (LED on)! See Fig. 8.13
Program number Number of stitches (1-250)
for seam section 1
Seam section number
Fig. 8.12
Program number Number of stitches (1-250)
for seam section 1
Seam section number
Fig. 8.13
Thread trimming at seam end key
p4xpd-2-en 8.13 08-08-29
