Pipe Parameter Entry Shortcuts
2.1
Dual function keys menu description
Press key
Display Net Flow Today /Flow Max /Flow Min/The
Average/Current Rate in turn.
Press key
Display Day Totalizer
Flow /Monthly Totalizer Flow
/ Yearly Totalizer Flow in turn.
Press key
Display Totalizer Start and Stop in turn.
Press key
Display instantaneous cool capacity and
cool
totalizer.
Press key
Display instantaneous heat capacity and heat capacity
totalizer.
Press key
Display the t
emp in, out and temperature difference
Press key
Display Flow Rate and Velocity.
Press key
Display Flow Sound Velocity.
Press key
Display Signal Strength and Signal Quality.
