PFlow Industries F Series User Manual

Section  | 2  Seies | 1570-000 | Rev  | 2022-03-01 | e-mail csd@pow.com
Section 8 | Electrical Overview
www.pflow.com
P 414 352 9000
F 414 352 9002
6720 N. Teutonia Ave.
Milwaukee, WI 53209
The motor / brake is located on the drivebase assembly. The motor and brake
wiring must be veried prior to energizing the VRC.
The F series VRC has eight (8) limit switches incorporated into a standard two-level
VRC: one (1) at each level to stop the carriage, one (1) overtravel, two (2) li chain
tensioner switches, and four (4) drive chain tensioner switches. All limit switches
require eld mounting and wiring. VRCs servicing more than two levels require
two (2) additional limit switches for each intermediate level.
Limit Switches
Drivebase
Assembly

PFlow Industries F Series Specifications

General

Brand	PFlow Industries
Model	F Series
Category	Lifting Systems
Language	English
