Twin Roller Guide Wheelblock Assembly RH - 17544-0200 Nyloil Wheels (green)
LH - 17544-1200
17544-0000.SMG
PFL-200117-1
1
2
3
4
2
3
5
10
11
9
5
6
6
12
13
7
8
Item Qty Part No. Description
1 4 7278-0036 Scew C 5-11  2.25 GR5
2 8 5858-0015 oc ase Std 5
3 8 6296-0015 ase Std lat 5
4 4 7278-0028 Scew C 5-11  1.75 GR5
5 2 17546-0000 in 30mm
6 2 17548-0000 eel loil 3.5  1.5
7 4 2888-0012 Scew SC 1-20  3
8 4 6708-0009 t oc lon 1-20
9 2 17545-0000 late Retaine
10 3 9237-0024 Scew C 12-13  1.5 GR5
11 3 5858-0013 oc ase Std 12
12 1 17561-0000 a Clamp
13 1 17840-0000 Gide Rolle loc sseml
14 1 17543-0000 loil eel sseml
17543-0000
PFL-200120-2
14
17544-0200
Note: Apply moly coat grease to inside
diameter of wheel prior to inserting pin.
17544-1200
