Mechanical Instructions
EN 10 LC7.2E LB4.
4.3.7 Main Supply Board
1. Refer to next figures.
2. Unplug all cables.
3. Remove the fixation screws [1].
4. Take the board out (it hinges at the left side).
Notes:
• Figure below can deviate slightly from the actual situation,
due to the different set executions.
• Follow the disassemble instructions in described order.
Figure 4-9 Main supply panel
H_17170_030.eps
220507
1
