Philips 3000 V2 - Coffee Grinder; Grinder Blades

PHILIPS 3000 V2 07 DISASSEMBLY
2/7
To extract the top support of the appliance, press on the grind-
ing adjustment spindle (A) and turn the support anticlockwise
until it unhooks.
Turn the grinder blades anticlockwise out of the support.
Turn the grinder blades clockwise out of the support. The
bayonet connections can be accessed from the rear.
For a standard adjustment, both markings
must be aligned.
7.3. Grinder blades
A
B
 7.2. Coeegrinder
Raise the coee grinder and remove the connections. When reassembling the coee grinder, make
sure the spring is repositioned correctly (see photo).
The new machines have a coee grinder with the screw to
prevent the disassembly of the upper coee grinder support
(see photo).
Caution in the new coee grinder with the screw, Unscrew this
last, before disassembly of the upper coee grinder support.
