Philips 3000 V2 - CPU Board; KYB Interface and Display

PHILIPS 3000 V2 07 DISASSEMBLY
6/7
7.14. KYB interface and display
Loosen the screws slide the card o the support and disconnect the
electrical connections.
Loosen the screw for remove the cover.
Remove the cover and disconnect the
electrical connections.
Press as photos and remove the
display support
Remove the keyboard
support
Remove the keyboard Remove the
silicon key
Remove the
front pannel
All component
7.12. CPU board
7.13. ProgrammingaccessforEPSC(EspressoPhilipsServiceCenter)
