Modbus description
106377_en_04 PHOENIX CONTACT 55 / 68
Hold-
ing
2000 16 bits Read – Configuration switch S1 Binary, 1 bit per DIP switch
2001 16 bits Read – Configuration switch S2 Binary, 1 bit per DIP switch
4000 16 bits Read/write Retentive Configuring the enable
charging process function via
input EN or Modbus registers
Switching on the PWM signal
if all other conditions required
are met.
Integer
0: Charging always enabled
1: Charging enabled if input EN =
ON (default)
2: Charging enabled in the event
of a pulsed signal at input EN,
reset upon next pulse
3: Charging enabled if value 1 is
written to register 20000.
Charging not enabled (PWM
OFF) if value 0 is written to regis-
ter 20000.
4001 16 bits Read/write Retentive Configuring external release
via input XR or Modbus regis-
ters
Setting status F (according to
IEC 61851-1) if charging sta-
tion is not available
Integer
If S1/DIP 2 = OFF:
0: Always available
(Default, if S1/DIP 2 = OFF, other
values have no effect)
If S1/DIP 2 = ON:
1: Available if XR = ON, status F
if XR = OFF
(Default, if S1/DIP 2 = ON)
2: Available if value 1 is written to
register 20001. Status F if value 0
is written to register 20001.
Table 9-2 Register assignment
Type Address Value Access Memory Function Coding
