The Inline controller under PC Worx/PC Worx Express
8385_en_02 PHOENIX CONTACT 73
3.13 Function blocks for handling files on the parame-
terization memory
The function blocks are used to access files from within the application program. Some of
the blocks support multiple instantiation. This means that it is possible to work with a number
of different files within the same project. The blocks perform the standard functions that are
required for typical file access operations.
The FILE_NOTIFY block is available in addition to the blocks for typical file access opera-
tions. This block can be used to detect files that have been modified in a directory containing
user files. These modifications may include:
– Deletion of one or more files
– Writing one or more new files
– Modification of one or more existing files
Both modifications made to this directory via FTP (remote) and modifications made locally
via function blocks or firmware services can be detected.
The functional blocks are valid for:
All file operations are subject to the following restrictions:
No directory hierarchies are supported. All file operations only affect the root directory of
the parameterization memory.
Order designation As of hardware version As of firmware version
ILC 131 ETH 00 4.00
ILC 151 ETH 00 4.00
ILC 171 ETH 2TX 00 4.00
ILC 191 ETH 2TX 00 4.00
ILC 131 ETH/XC 00 4.00
ILC 151 ETH/XC 00 4.00
Table 3-3 Overview of the function blocks
Function block Short description
FILE_OPEN Opens a file with a specific name
FILE_CLOSE Closes a file with a specific handle
FILE_READ Reads from a file with a specific handle
FILE_WRITE Writes to a file with a specific handle
FILE_REMOVE Deletes a file with a specific name
FILE_TELL Determines the current position of the file pointer in a file
FILE_SEEK Moves the current file pointer to a new position
FILE_NOTIFY Displays files that have recently been created, deleted or mod-
ified
The function blocks for handling files on the parameterization memory are described in
the PC Worx online help.
