Refitting the hub bearings
- Install the three shafts in the engine crankcase
as shown in the figure.
Refitting the ub cover
- Fit a new gasket together with the centring dow-
els.
- Seal the gasket of the breather pipe using black
silicone sealant.
- Fit the gearbox cover, making sure the breather
pipe is in the correct position.
- Position the shorter screw that can also be rec-
ognised from the different colour as shown in the
figure.
- Fix the breather tube support by means of the
lower screw.
- Fit the remaining screws and tighten the seven
screws to the prescribed torque.
Flywheel cover
Engine MP3 250 i.e.
ENG - 22
