Shock absorber lower clamp 33 ÷ 41 Upper shock absorber clamp 33 ÷ 41
Centre-stand
REMOVAL
- Use a jack to support the vehicle properly.
- Remove the two return springs from the centre
stand.
- Undo the nut shown in the figure.
- Remove the bolt from the right side.
- Remove the centre stand.
FITTING
- On refitting tighten the nut to the specified torque.
Locking torques (N*m)
Centre stand bolt 31 ÷ 39
MP3 250 i.e. Suspensions
SUSP - 53
