PIAGGIO 633823 - Removing the Starter Motor

Removing the starter motor
- Remove the two screws indicated in the figure.
- Take the starter motor out of its seat
Removing the flywheel magneto
- Remove the water pump shaft and crankshaft
spline clip
- Line up the two holes in the flywheel as shown in
the photo
- Screw in the guide bushing that is part of the
special flywheel stop tool on the flywheel as shown
in the photo.
MP3 250 i.e. Engine
ENG - 25
