- Using the special flywheel stop tool, tighten up
the flywheel fixing nut to the prescribed torque
-Refit the retention plate
Specific tooling
020627Y Flywheel lock wrench
Locking torques (N*m)
Flywheel nut 94 ÷ 102
Refitting the starter motor
- Fit a new O-ring on the starter motor and lubricate
it.
- Fit the starter on the crankcase, locking the two
screws to the prescribed torque.
Locking torques (N*m)
Starter motor screws 11 ÷ 13
Cylinder assy. and timing system
Removing the intake manifold
Loosen the three screws and remove the air intake manifold.
- When refitting, secure to the specified torque.
Engine MP3 250 i.e.
ENG - 28
