11.Fuse No. 10 7.5A
12.CAN line connection with tilt locking electric control unit
13.Fuse No. 8 10A
14.Starter button
15.Injection load remote control
16.Starter remote control
17.Electric fan starter
18.Starter motor
19.Electric fan motor
20.Fuel pump
21.H.V. coil
22.Fuel injector
23.Lambda sensor
24.Engine "WARNING" light
25.Immobilizer LED
26.Diagnostics connector
Troubleshooting procedure
Engine does not start
ENGINE DOES NOT START IF ONLY PULLED
Possible Cause Operation
Immobiliser enabling signal System not encoded
System not efficient, repair according to the indi-
cations of the self-diagnosis
Presence of faults detected by the self diagnosis Pump relay
HV coil
Injector
revolution timing sensor
Fuel supply Fuel in the tank
Fuel pump activation
Fuel pressure (low)
Injector capacity (low)
Power to the spark plug Shielded spark-plug cap HV coil (secondary insu-
lation)
Parameter reliability Coolant temperature
Distribution timing - injection ignition
Intake air temperature
End of compression pressure End of compression pressure
Injection MP3 250 i.e.
INJEC - 8
