Removing the hub cover
- Remove the clip fixing the hose to the cylinder.
- Remove the ten fixings
- Remove the flywheel cover.
Removing the stator
- Remove the two pickup screws and the screw
holding the wiring support and the three stator
clamping screws shown in the figure.
- Remove the stator and its wiring.
MP3 250 i.e. Engine
ENG - 23
