Fit the bracket locking the parallelo-
gram in the holes of the previously re-
moved screws; use the screws sup-
plied with the tool and be careful to
correctly centre the spacer in the bear-
ing.
•
Remove the nut fixing the steering con-
trol arm and keep the original washer
in position.
•
Fit the steering guiding bracket in a
straight riding position, fix one end to
the attachment of the half-arm coupling
flange and the other end to the screw
fixing the steering control arm.
•
Place the frame so that the sliders
come into contact with the rim maxi-
mum diameter but without interfering
with the tyre. If required, reposition the
frame by operating the 3 adjustable
support feet.
Suspensions MP3 250 i.e.
SUSP - 46
