Legshield
Remove the front headlight assembly.
Remove the spoiler.
Remove the two front screws and the two screws
under the wheelhouse.
Remove the four screws on the shield back plate.
See also
spoiler
Headlight assy.
Knee-guard
- Remove the front shield.
- Remove the spoiler.
- Remove the two central screws and the coolant
cap cover screw.
MP3 250 i.e. Chassis
CHAS - 5
