- Disconnect the connectors from the flywheel wir-
ing as shown in the photo.
- Remove the cable from the retaining clip on the
flywheel cover.
Remove the lower screw of the left-hand shock
absorber.
- Use a jack to support the vehicle properly. Re-
move the engine-swinging arm fixing pin by undo-
ing the nut and the head of the pin as shown in the
photograph.
- The engine is now free.
When refitting the engine onto the scooter, carry out the removal operations but in reverse order and
respect the tightening torques shown in the Specifications Chapter.
-Check the engine oil level and if necessary top it up with the recommended type.
- Fill and bleed the cooling circuit.
- Check the functioning of the accelerator and the electrical devices.
CAUTION
MP3 250 i.e. Engine from vehicle
ENG VE - 5
