Version 125
- Remove the 4 screws and the housing.
- Remove the five screws on two different levels
as well as the small casing.
Removing the driven pulley shaft bearing
- Remove the clip from the inside of the cover.
- Remove the bearing from the crankcase by
means of:
Specific tooling
020376Y Adaptor handle
020375Y Adaptor 28 x 30 mm
020412Y 15 mm guide
Engine B 125-250
ENG - 104
