Braking system
Level check
The brake fluid tanks for the front and rear brakes
are located on the pumps under the handlebar
cover. Proceed as follows:
- Bring the scooter onto the centre stand and with
the handlebar centred; - check the fluid level at the
sight glass as shown in the figure.
A certain lowering of the level is caused by wear
on the pads.
Top-up
- Remove the cap on the handlebar cover as
shown in the photograph.
B 125-250 Maintenance
MAIN - 53
