PIAGGIO B 250 - Removing the Stator

Removing the hub cover
- Remove the clip fixing the hose to the cylinder.
- Remove the 10 fixings
- Remove the flywheel cover.
- Remove the two clamps, the two couplings and
empty the cooling system.
- Remove the 4 retainers and the flywheel cover
Removing the stator
- Remove the two pickup screws and the screw
holding the wiring support and the three stator
clamping screws shown in the figure.
- Remove the stator and its wiring.
B 125-250 Engine
ENG - 131
