PIAGGIO B 250 - Front Mudguard

Front mudguard
- Remove the retaining screw of the cable lead
through support on the right-hand side of the mud-
guard. - Loosen the 3 fixing retaining screws indi-
cated in the figure and remove the mudguard.
Radiator fan
- Remove the front wheel housing.
- Prepare a container for the coolant.
- Remove the expansion tank outlet and return
pipes.
- Remove the coolant supply and return pipes from
the radiator.
- Loosen the screw mounting the radiator to the
frame.
- Disengage the radiator and the electric fan.
See also
Front wheel housing
Flyscreen
- Remove the front handlebar cover
- Remove the 3 screws shown in the photograph.
See also
Front handlebar cover
Chassis B 125-250
CHAS - 280
