Removal
- Remove the rear handlebar cover.
- Remove the pin mounting the handlebar to the
steering tube.
- Remove the handlebar and place it on the rear
cover of the front shield.
See also
Rear handlebar cover
Refitting
- Install the handlebars on the steering tube, paying attention to the centring, aligning the recess on the
handlebar with that on the steering tube as shown in the figure.
- Tighten the handlebar fixing screw on the steering tube to the prescribed torque.
Locking torques (N*m)
Handlebar fixing screw (*) 45 ÷ 50
(*) Lubricate the nuts with engine oil before instal-
lation
Front fork
B 125-250 Suspensions
SUSP - 221
