Discharge: 0.15 mm (when cold)
Cooling system
Level check
- To check the level, it is necessary to look inside the expansion tank: a mark on the side of the filler
indicates MIN and MAX levels.
Top-up
The fluid level inspection should be carried out every 6,000 km when the motor is cold, following the
methods indicated below:
Place the scooter on its centre stand and on flat ground.
- Undo the screw shown in the figure and remove the expansion tank cap on RHS.
- Remove the cap of the expansion tank and top up the fluid level if it is near or below the MIN mark
inside the tank. The coolant level must always be between MIN and MAX. level.
-The coolant consists of an ethylene glycol and corrosion inhibitor based 50% de-ionised water- anti-
freeze solution mix.
CAUTION
DO NOT EXCEED THE MAX. LEVEL WHEN FILLING SO AS TO AVOID THE COOLANT ESCAPING
FROM THE EXPANSION TANK WHEN THE vehicle IS IN USE.
Maintenance B 125-250
MAIN - 52
