Perform this operation when the engine cold, as
described below:
1) Put the vehicle on its central stand on a flat sur-
face.
2) Unscrew dipstick "A", dry it with a clean cloth
and refit by screwing it completely.
3) Remove the dipstick again and check that the
oil level is between the MAX and MIN marks on the
dipstick; top up if necessary.
The MAX level mark indicates an amount of about
1100 cc of engine oil. The level will be lower if
checked after using the vehicle (i.e. when the en-
gine is hot). To obtain a correct indication of the oil
level, wait for at least 10 minutes after switching
off the engine.
Characteristic
Engine oil (125)
~ 1100 cc
Engine oil (250)
~ 1200 cc
The oil should be topped up after having checked the level and in any case by adding oil without ever
exceeding the MAX. level.
Restoring the level between the MIN and MAX reference marks requires ~ 400 cm³ of oil.
Engine oil filter
The cartridge filter must be replaced every time the oil is changed. Use new oil of the recommended
type for topping up and changing purposes.
Make sure the pre-filter and drainage plug O-rings are in good conditions. Lubricate them and refit the
mesh filter and oil drainage plug, screwing them up to the specified torque. Refit the new cartridge filter
being careful to lubricate the O-ring before fitting it. Change the engine oil.
Recommended products
AGIP CITY HI TEC 4T Engine oil
SAE 5W-40 Synthetic oil that exceed the requirements of API SL, ACEA A3, JASO MA specifications
Oil pressure warning light
The vehicle is equipped with a warning light on the instrument panel that lights up when the key is turned
to the "ON" position. However, this light should switch off once the engine has been started.
Maintenance B 125-250
MAIN - 50
