PIAGGIO B 250 - Instrument Panel

Rear handlebar cover
- Remove the front handlebar cover.
- Remove the 3 screws shown in the photograph.
- Remove the 2 screws on the rear part of the han-
dlebar cover shown in the photograph.
See also
Front handlebar cover
Instrument panel
- Remove the rear handlebar cover.
- Disconnect the cable harness.
- Remove the odometer cable.
- Remove the 3 screws shown in the photograph.
- Remove the instrument panel.
See also
Rear handlebar cover
Front handlebar cover
- Remove the 5 screws on the front part of the
handlebar cover shown in the figure.
- Remove the 2 screws on the rear part of the han-
dlebar cover shown in the figure.
Chassis B 125-250
CHAS - 272
