Crankshaft oil seals
Removal
- First remove the transmission cover and the com-
plete driving pulley
- Install the base of the appropriate tool on the oil
guard using the screws provided.
Specific tooling
020622Y Transmission-side oil guard punch
- Screw the threaded bar onto the base of the tool
and extract the oil guard.
Specific tooling
020622Y Transmission-side oil guard punch
Refitting
- Use a new oil seal upon refitting.
- Prepare the new oil seal, lubricating the sealing
lip.
- Preassemble the oil seal with the specific tool,
positioning the screws.
- Place the sheath over the crankshaft.
- Insert the tool with the oil seal on the crankshaft
until it comes into contact with the crankcase.
B 125-250 Engine
ENG - 181
