Removal
- Remove the rear wheel.
- Remove the hub and the brake disc.
- Carry out the same procedure with the front brake
disc.
See also
Removing the rear wheel
Refitting
- For the installation, position the disc correctly using the arrow stamped on it as reference.
- Tighten the screws to the prescribed torque and apply the recommended product.
N.B.
THE SURFACE OF THE DISC WITH THE STAMPED ARROW FOR THE DIRECTION OF ROTATION
MUST FACE TOWARDS THE OUTSIDE OF THE SCOOTER.
Recommended products
Loctite 243 Medium strength threadlock
Loctite 243 medium-strength threadlock
Locking torques (N*m)
Brake disc fixing screws 11 ÷ 13
Disc Inspection
Checking the disc is important; it must be perfectly
clean, with no sign of rust, oil or grease or any oth-
er dirt, and must show no signs of deep scoring.
Characteristic
New rear disc thickness
4.0 mm
Disc thickness at wear limit (rear)
3.5 mm
Braking system B 125-250
BRAK SYS - 244
