distance of more than 1500 km. If leaks continue or in the event of real losses, the ceramic seal should
be replaced. For these operations, observe the tools and instructions given in the relevant service
station manuals.
Note: The ceramic seal may be overhauled according to the following couplings:
•
Coupling "A": seal ring no. 485084 with ceramic seal no. 486216
•
Coupling "B": seal ring no. 841329 with ceramic seal no. 841330
The couplings above may be selected according to their availability, as they are interchangeable.
Removal
- Loosen the two screws indicated in the figure and
remove the thermostat cover.
- Remove the thermostat with its gasket.
Check
1) Look to see that the thermostat is not damaged.
2) Fill a metal container with approx. 1 litre of wa-
ter.
Immerse the thermostat, and keep it in the centre
of the container.
Immerse the multimeter temperature probe draw-
ing No° 020331Y closeà to the thermostat.
Heat the container with a hot air gun drawing No°
020151Y.
Check the temperature when the thermostat starts
to open:
Opening start temperature: 69.5 ÷72.5°C
Heat up until the thermostat is completely open.
Opening travel: 3.5 mm at 80°C
CAUTION - To execute the test correctly, make
sure neither the thermostat nor the thermometer
touches the container.
B 125-250 Cooling system
COOL SYS - 267
