- Loosen the 2 screws shown in the figure.
- Remove the legshield.
See also
Headlight assy.
Frame central cover
Knee-guard
- Remove the legshield; - Remove the 2 fixing
screws of the fuse box in the front glove box; -
Separate the electrical connections; - Remove the
expansion tank; - Loosen the fixing screw inside
the glove box and the two screws located under
the central frame cover; - Disconnect the saddle
closing mechanism; - Remove the rear shield with
the glove box.
See also
Legshield
Chassis B 125-250
CHAS - 274
