DATA
Version 500
Engine Single cylinder, four stroke, four
valves, cam mounted single
crankshaft chain driven on
magneto side.
Bore x stroke 92 X 69 mm
Cubic capacity 460 cm³
Compression ratio 10.5: 1
Ignition advance (before TDC) Variable advance controlled by the
injection control unit
Fuel supply 38 Ø mm throttle body and single
injector
Spark plug
•
NGK CR7EKB
•
Champion RG6YC
Max. speed 160 km/h
Valve clearance intake: 0.15 mm discharge (when
cold): 0.15 mm (when cold)
RPM 1500 ± 50 revs/min
TECHNICAL DATA
Maximum width 910 mm
100
