03_31
03_32
03_33
Headlight adjustment (03_33, 03_34)
Proceed as follows:
1. Position the unloaded scooter, in running order and with the tyres inflated to the
prescribed pressure, on a flat surface 10 m away from a half-lit white screen; ensure
that the longitudinal axis of the scooter is perpendicular to the screen;
2. Turn on the headlight and check that the borderline of the projected light beam
should be lower than 9/10 of the distance from the ground to the centre of the vehicle's
headlight, and higher than 7/10;
3. If not, adjust the projection by turning the central screw «A» set inside the glove
box.
87
