03_22
03_23
03_24
Battery (03_22, 03_23, 03_24)
To access to the battery, proceed as follows:
1. Rest the vehicle on the central support;
2. Open the saddle as described above, see section «Opening the saddle to access
the helmet compartment»;
3. Remove the fasteners «A» and the small cover «B». Remove screws «C», raise
the stop light support «D».
4. Release the elastic band.
The battery is the electric device that requires the most assiduous surveillance and
the most diligent maintenance. The main maintenance regulations to be carried out
are as follows:
WARNING
DO NOT DISCONNECT THE BATTERY CABLES WITH THE ENGINE RUNNING,
THIS CAN CAUSE PERMANENT DAMAGE TO THE VEHICLE ELECTRONIC CON-
TROL UNIT.
Electric characteristic
Battery
12V - 14 Ah
78
