Starting up the engine (02_06, 02_07, 02_08, 02_09)
The vehicle is fitted with an ignition disabling system controlled by the side stand and
the engine cut-off switch. The engine cannot start if the side stand is down or if the
emergency cut-off switch is set to «OFF». If the engine is on, it turns off when the side
stand is lowered or the emergency cut-off switch is turned to «OFF». The appropriate
warning light on the digital instrument panel «D» signals this situation. The scooter is
equipped with automatic transmission with direct drive, so that starting is effected by
turning the throttle grip to idle speed; to start-off from still, progressively twist the
throttle grip. In order to start the engine and before pressing the starter button «E», it
is necessary to pull and hold pulled the front brake lever «G» or the combined brake
lever «D» to actuate the safety switches. The fuel supply system can control ignition
based on the engine condition (hot/cold) or the ambient temperature and pressure.
1. Put the scooter on the centre stand "F", making sure the rear wheel is raised from
the ground.
2. Keep the throttle grip «C» completely untwisted.
3. Insert the key into the ignition switch "A" and turn to position "ON".
4. Make sure that switch «B» «RUN OFF» is set to «RUN» position and that the side
stand «L» is raised.
5. Pull either the front «G» or the combined brake lever «D» while pressing the starter
button «E»
WARNING
THE AUTOMATIC TRANSMISSION MAKES THE REAR WHEEL TURN EVEN
WHEN THE THROTTLE IS SLIGHTLY TWISTED. RELEASE THE BRAKE CARE-
FULLY AFTER STARTING, AND THEN ACCELERATE GRADUALLY.
NEITHER PUSH THE START BUTTON WHEN THE TANK IS EMPTY NOR TURN
THE KEY SWITCH TO «ON» TO AVOID DAMAGING THE INJECTION SYSTEM.
