WARNING
SPENT BATTERIES ARE HARMFUL FOR THE ENVIRONMENT. COLLECTION
AND DISPOSAL SHOULD BE CARRIED OUT IN COMPLIANCE WITH CURRENT
REGULATIONS.
Fuses (03_25, 03_26, 03_27)
The electric system is equipped with:
1. four fuses «A» located in the fuse box under the saddle;
2. four fuses «B» located in the glove box;
3. four fuses «C» and a 70A fuse «D» located in the battery compartment on the left
side of the vehicle.
4. a 30A fuse (main fuse), located next to the battery on the right side, a spare fuse is
positioned below it.
The tables show the position and the characteristics of the fuses present in the vehicle.
CAUTION
BEFORE REPLACING A BLOWN FUSE, FIND AND SOLVE THE FAILURE THAT
CAUSED IT TO BLOW. NEVER TRY TO REPLACE THE FUSE WITH ANY OTHER
MATERIAL (E.G., A PIECE OF ELECTRIC WIRE).
81
