PIAGGIO X9 Evolution 500 - Page 82

FUSES
Electro-hydraulic stand CAPACITY: 5A
PROTECTED CIRCUITS: Electro-
hydraulic stand
LOCATION: Battery compartment
left side of vehicle
Immobilizer (CPU decoder) CAPACITY: 3A
PROTECTED CIRCUITS:
Immobilizer (CPU decoder)
LOCATION: Battery compartment
left side of vehicle
Fuel pump - Injector - H.T. Coil CAPACITY: 10A
PROTECTED CIRCUITS: Fuel
pump - Injector - H.T. Coil
LOCATION: Battery compartment
left side of vehicle
Consensus for electronic CPU
Decoder
CAPACITY: 5A
PROTECTED CIRCUITS:
Consensus for electronic CPU
Decoder
LOCATION: Battery compartment
left side of vehicle
12V socket for electrics - Helmet
compartment light
CAPACITY: 15A
82
3 Maintenance
