PIAGGIO X9 Evolution 500 - Page 83

PROTECTED CIRCUITS: 12V
socket for electrics - Helmet
compartment light
LOCATION: Saddle compartment
Saddle opening by button CAPACITY: 10A
PROTECTED CIRCUITS: Saddle
opening by button
LOCATION: Saddle compartment
PICS device CAPACITY: 10A
PROTECTED CIRCUITS: PICS
device
LOCATION: Saddle compartment
High beam and dipped beam lamp CAPACITY: 7,5A
PROTECTED CIRCUITS: High
beam and dipped beam lamp
LOCATION: Saddle compartment
Horn - High beam lamp (passing) -
Accessories
CAPACITY: 15A
PROTECTED CIRCUITS: Horn -
High beam lamp (passing) -
Accessories
LOCATION: Glove box
Start consensus - Stop lamp CAPACITY: 7,5A
PROTECTED CIRCUITS: Start
consensus - Stop lamp
83
3 Maintenance
