LOCATION: Glove box
Front and rear position lamps and
license plate light
CAPACITY: 7,5A
PROTECTED CIRCUITS: Front
and rear position lamps and
license plate light
LOCATION: Glove box
PICS - Saddle opening by remote
control
CAPACITY: 7,5A
PROTECTED CIRCUITS: PICS -
Saddle opening by remote control
LOCATION: Glove box
General - Main circuits CAPACITY: 30A
PROTECTED CIRCUITS: General
- Main circuits
LOCATION: Battery compartment
right side of vehicle
Electro-hydraulic stand CAPACITY: 70A
PROTECTED CIRCUITS: Electro-
hydraulic stand
LOCATION: Battery compartment
left side of vehicle
84
3 Maintenance
