Piazzetta P960 - Dimensional Diagram P960; Dimensional Diagram P961

DT2032919-00
2.5 dIMENSIONAL dIAGRAM P960
DT2032920-00
2.6 dIMENSIONAL dIAGRAM P961
24,72"
(628 mm)
21,27"
(540 mm)
45,85"
(1165 mm)
3,03"
77 mm
12,7"
(323 mm)
Ø 1,97"
(50 mm)
Ø 2,95"
(75 mm)
10,83"
(275 mm)
3,66"
(93 mm)
4,33"
(110 mm)
7,48"
190 mm
1,37"
(35 mm)
6,76"
(172 mm)
26,57"
(675 mm)
21,76"
(553 mm)
45,85"
(1165 mm)
3,03"
(77 mm)
6,76"
(172 mm)
12,7"
(323 mm)
Ø 1,97"
(50 mm)
Ø 2,95"
(75 mm)
10,83"
(275 mm)
3,66"
(93 mm)
4,33"
(110 mm)
7,48"
(190 mm)
1,37"
(35 mm)
